Accurate topographical model for public consultation.
This 2.5m x 2.5m model was commissioned as part of a public consultation process for a proposed development just off the M1. Comprising 6 A0 sized sections, the purpose of the model was to demonstrate how high embankments and landscaping around the site would screen it from surrounding villages. For this reason it was important that the proposed on-site levels and surrounding topography were all accurately recreated. The buildings are only shown as massing blocks due to the small scale (1:1250). Each metre is represented by just 0.8mm, so that the 16 metre high commercial buildings shown on the model are only approx. 13mm high.
Exhibition display for “Jumping Pillows”.
The client for this project “Jumping Pillows”, who specialise in installing inflatable play areas, asked us to design and build an eye catching model for use at exhibition events around the UK. We based this model on one of their recent installations and gave it strong colours and realistic detail so that it really draws the eye. The fencing and picnic tables give a good sense of scale but we also supplied some clear silhouette figures that the client could place on the model as an additional detail if required (you can see these better if you click on the two smaller pics above).
Mobile display models for a ground breaking construction product.
Concrete Canvas, a South Wales based company with an innovative, concrete based construction material, commissioned us to produce 8 mobile display models for use by their sales team. The displays were designed to demonstrate the speed and simplicity of construction using their unique, concrete based fabric which comes on a roll but sets solid when soaked with water. We made the ditch and bund profiles using the actual product formed over simulated earthworks. Each model was supplied with a purpose-built flight case (shown in main image) to protect it in transit and for storage when not in use.
A room divide with a difference!
We don’t just do models! When our website guys “Designer Websites” asked if we could come up with a quirky installation for their refurbished meeting room we suggested this “designer” partition wall featuring custom-made tiles and a hidden door. They needed to divide the room and we felt this was a more interesting solution than a painted stud partition wall with a standard door. The tiles are made from back-sprayed clear acrylic using colours from their logo and arranged in a pattern they designed themselves. The flush fitting “secret” door closes automatically to avoid the need for a handle on the facing side. The whole installation was built in our workshop in three sections so that it could be delivered and installed on site with minimum disruption. Designer Websites were keen to get us involved because all the main refurbishments in the room (floor, signage, table, blinds, etc.) were provided by other companies they’d built websites for – a good opening talking point for meetings with potential new clients.
The partition and secret door can be seen at the beginning of this video:
Cut-away view of turbines and sluice gates
Designed and constructed within two weeks for a presentation at the House of Commons, the main problem we had with this model wasn’t the tight deadline but how best to show an underwater view of the power generating turbines at the heart of this renewable energy project. We also had to illustrate different water levels on the inside and seaward side of the lagoon structure. Our solution was to create the water as a thin clear layer with a sprayed on rippled, surface finish and then cut out large viewing “windows” on either side of the turbine structure. This allowed clear low angle views through the turbines as can be seen from the inset pic above.
