White styled model to show proposed new development area.

We’ve worked with several different county councils across the UK but, as you’d expect, we’ve done a lot of work for our local county council and this master plan model is our latest project for them. Commissioned as a part of public consultation process one of the major purposes of the model is to demonstrate the scale and extent of a proposed major redevelopment of the area, including a new Arena venue for concerts and events. Although it’s hard to pick up in these photos, the existing on-site buildings are shown in light grey and the proposed new buildings are shown in white. The model also incorporates LED illumination which is used to highlight some of the key proposals.

Cut-away view of turbines and sluice gates

Designed and constructed within two weeks for a presentation at the House of Commons, the main problem we had with this model wasn’t the tight deadline but how best to show an underwater view of the power generating turbines at the heart of this renewable energy project. We also had to illustrate different water levels on the inside and seaward side of the lagoon structure. Our solution was to create the water as a thin clear layer with a sprayed on rippled, surface finish and then cut out large viewing “windows” on either side of the turbine structure. This allowed clear low angle views through the turbines as can be seen from the inset pic above.

With remote controlled illumination of water.

This simple but eye catching model was commissioned to illustrate the size and position of two proposed tidal lagoons in the Bristol Channel. The lagoons are designed to generate renewable energy by harnessing the rise and fall of the tides in an area that has the second highest tidal range in the world. The topography is represented as a stylized contour map (with exaggerated vertical scale) laser-cut from white acrylic sheet. The water is shown as blue acrylic with LED edge-lighting to add visual interest. The LEDs can be set to varying brightness and colour using a hand held remote control (visible on the front edge of the model in the main pic above).

White styled model showing internal room layout.

We produced two conventional housing models last month but this small model was a bit different, showing the internal room layout of the four standard designs on offer in a large apartment block. The stylised internal modelling is considerably less expensive than realistic colour and detail but still gives a clear indication of room function and spatial organization within the apartment. At 1:50 scale the model base is less than a metre long so doesn’t require too much space in a sales office.

David Cameron views two of our models



A few days after completing these two white styled models we were surprised (and pleased) to discover they had been the focal point for a presentation to David Cameron about the Swansea Lagoons tidal energy project (apparently they couldn’t tell us beforehand for security reasons). The models are both at 1:1000 scale and show two different areas of the lagoon structure. The largest model shows the leisure facilities where the lagoon wall joins the mainland whilst the small model shows where the turbines generate electricity from the twice daily rise and fall of the tide (the Bristol Channel has the second highest tidal range in the world). If you click on the images to enlarge them you’ll see that even at this small scale (1mm represents 1 metre) we can show a high level of detail.

Our Latest Projects | Modelmakers | All posts tagged '120-scale-model'

Model creates focal point for marketing suite.

When we delivered this model to the on-site marketing suite the client was really pleased to see how much of the architectural character of the buildings we’d been able to represent. The model was at 1:200 scale and showed phase 1 comprising three refurbished and renovated buildings in full detail and phase 2, three new-build apartment blocks, in simplified massing form. Fully detailed phase 2 buildings will be added at a later stage. If you click on the photos to enlarge them you should be able to fully appreciate the high level of detail we can achieve at this scale.

3 storey model helps artists plan their shows

















An art gallery in London asked us to produce 10 sets of these floor plate models to help artists design upcoming shows. Each set consisted of 3 storeys and showed the circulation routes and available floor and wall space on each level so that the artist could plan the positions of paintings or other exhibits in their show. At 1:20 scale the floor plans are very large so we designed a flat-pack solution which allowed the artists to take the three floor layouts as portable kits that could be easily assembled at a later date. We created our own CAD files for all components and then laser cut the floors and walls out of 5mm acrylic. Stairwells, WCs and other facilities were indicated by laser-engraved lines on the floor plates.

 “Drivetrain” for wind turbine – Scale 1:20





















A “Drivetrain”, in case you were wondering, is the component that harnesses the power from the revolving blades of a wind turbine – it’s the machinery the blades are connected to at the top of the tower, normally hidden under a cowling. This particular model was commissioned for use as an eye catching display at trade shows and exhibitions. It was designed to illustrate the flexible, modular nature of the client’s product which could be easily adapted for different types of wind turbine. Taking the real thing along wasn’t really an option due to its massive size and weight. If you click on the images to enlarge them, you’ll see the outline of a standing figure which gives a sense of the machine’s real life dimensions. At 1:20 scale we were able to show a plenty of realistic detail, including individual nuts and bolts and the huge single disc brake with four callipers on the back face of the model.

Three 1:20 scale industrial transformer models completed for export





















We actually completed these models last month, a week ahead of schedule and they are now about to head off abroad, two to China and one to Brazil. They are part of an order for four identical 1:20 scale models, the first of which was completed and delivered before Christmas. If you click on the images to enlarge them, you’ll be able to see the high level of detail we can achieve at this large scale (the models are over a metre long). We made a similar model for the client over a year ago and it generated such a positive response from their overseas colleagues that they’ve come back to us for more.

 Brazil, China... Stafford – More models off to exotic locations!

















After sending five models to Russia last month we’ve just received a new multiple export order – two models for Brazil, one for China... and one up the M6 to Stafford where the client’s UK facility is based. The orders are for four identical 1:20 scale industrial transformer models similar to the one illustrated above. We actually made this model for the client last year and it generated such a positive response from their overseas colleagues that they’ve come back to us for more. As part of the project we’ll be supplying specially made shipping crates to protect them on their travels.
